C-FRAME MOTOR

Application/Features

RoHS Compliant
Open Enclosure
CW/CCW Shaft End
Sleeve Bearings
Ball Bearing
Thermally protected
Includes 2 Prong Plug
The Shaded-Pole Motors employ a Class 130(B) Insulation System
Rotation is Determined by Viewing the Shaft End
Evaporators, Refrigerators, Range Hoods, Ventilators, Exhaust Fans and Unit Heaters

INFORMATION:

Model	Stack Size （inch）	Stack Size （mm）	Volts	Hz	Output Power	RPM	Accessories
YJF61 Series	3/8"	10	120 240 120/240	50/60	4	1000-3200	Fan Blade/ Mounting Bracket/ Other
	1/2"	13			6
	5/8"	16			8
	3/4"	19			10
	7/8"	22			12
	1"	25			14
	1-1/16"	27			16
	1-1/8"	29			20
	1-1/4"	32			25
	1-1/2"	38			30
